Power-over-Ethernet (PoE) technology integrates power and data over an Ethernet cable, providing more flexibility in today’s workplace environment. By integrating power into a standard LAN infrastructure, PoE technology enables power to be supplied to network devices, such as IP phones, network cameras and wireless access points. As a result, when combined with a UPS, businesses are fully optimized for continuous operation, virtually eliminating power interruptions and business downtime. With the ability to install virtually anywhere, PoE technology allows for a scalable and flexible networking infrastructure for growth needs.
POE48-120BT-R
Manufacturer
Phihong
Power
48.00 W
POE48-120BT-R
Manufacturer
Power
48.00 W
Input voltage
44-57VDC
Efficiency
0.00
Max output current
0.00
Power/port
48W
Connector
RJ45
Electronic load input rating power
0.00
Warranty
1 year
Dimensions
162.25x65x36 mm
Weight
0.2
Water-cooled option
No
Features:
Compliant with the IEEE802.3bt Standard
Works with any layer 1 IEEE802.3bt Power Sourcing Equipment
Power On LED
Non-Vented Case
Gigabit Compatible
1 Year Warranty
Full Protection (OTP, OCP, OVP)
Download datasheet
POE60U-BTAX660-R
Manufacturer
Phihong
Power
60.00 W
POE60U-BTAX660-R
Manufacturer
Power
60.00 W
Input voltage
90-264Vac
Efficiency
0.00
Max output current
0.00
Power/port
60W
Connector
RJ45
Electronic load input rating power
0.00
Warranty
1 year
Dimensions
140x67x38 mm
Weight
0.27
Water-cooled option
No
Features:
Compliant with IEEE802.3bt Standard
Compliant with Phihong Proprietary 12.5K Detection
4 Pair Powering +3, 4, 5, 6/ -1, 2, 7, 8
Non-Vented Case
Multi-Gigabit Data Rates (1G, 2.5G, 5G, 10G) Models Available
DoE Level VI Compliant
Full Protection OCP, OVP
Limited Power Source (LPS)
1-year Warranty
Download datasheet
POE60S-1BT-R
Manufacturer
Phihong
Power
60.00 W
POE60S-1BT-R
Manufacturer
Power
60.00 W
Input voltage
90-264Vac
Efficiency
0.00
Max output current
0.00
Power/port
60W
Connector
C14
Electronic load input rating power
0.00
Warranty
1 year
Dimensions
160x180x50
Weight
1.7
Water-cooled option
No
Features:
Compliant with IEEE802.3bt/at/af Standard
4 Pair Powering +3,6,4,5 / - 1,2,7,8
Non-Vented Case
60W POE Power
Extends Ethernet to 200 Meters with copper,(can be even more with Fiber)
Standard SFP Module Input
Converts SFP to POE (converts fiber to copper)
Limited Power Source
Full Protection OVP, OCP
Single Source 4 Pair Power Current Sharing
1 Year Warranty
Gigabit Compatible
Download datasheet
POE60U-1BT
Manufacturer
Phihong
Power
60.00 W
POE60U-1BT
Manufacturer
Power
60.00 W
Input voltage
90-264Vac
Efficiency
0.00
Max output current
0.00
Power/port
60W
Connector
C14
Electronic load input rating power
0.00
Warranty
1 year
Dimensions
163.25x65x36 mm
Weight
0.3
Water-cooled option
No
Features:
Compliant with IEEE802.3bt Standard
Compliant with Phihong Proprietary 12.5K Detection
4 Pair Powering +3, 4, 5, 6 / -1, 2, 7, 8
Non-Vented Case
Multi-Gigabit Data Rates (1G, 2.5G, 5G, 10G) models available
DoE Level VI Compliant
ErP/Ecodesign Directive 2009/125/EC – Regulation EU 2019/1782 Compliant
Full Protection OCP, OVP
Limited Power Source (LPS)
1-year Warranty
Download datasheet
POEO75U-1BT-R
Manufacturer
Phihong
Power
75.00 W
Package
Outdoor midspan IP67
POEO75U-1BT-R
Manufacturer
Power
75.00 W
Package
Outdoor midspan IP67
Input voltage
90-264Vac
Efficiency
0.00
Max output current
0.00
Power/port
75W
Connector
RJ45
Electronic load input rating power
0.00
Warranty
1 year
Dimensions
246x170x58.5 mm
Weight
2.2
Water-cooled option
No
Features:
Compliant with the IEEE802.3bt Standard
Gigabit Compatible
IP67 Rating(waterproof)
-40°C to +65°C Temperature Range
Up to 90W with Derated Temperature
Non-Vented Case with Mounting Bracket
Full Protection OCP, OVP
1-Year Warranty
Cable Glands and AC connector included for Waterproof Operation
