Electronic DC-Loads
PLZ70UA
| Manufacturer | Kikusui |
| Power | 75.00 W |
| Package | 3U |
| Available DC input range | 0-150 |
PLZ70UA
| Manufacturer |
|
| Power | 75.00 W |
| Package | 3U |
| Input voltage | 90-250 Vac 1-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-150 |
| Max output current | 0.00 |
| Electronic load input rating power | 75.00 |
| Electronic load input rating current | 15 |
| Warranty | 1 year |
| Dimensions | 470x145x315 |
| Weight | 7 |
| Water-cooled option | No |
| Interface options | GPIB option |
Features:
|
|
| Description: The PLZ-U Series provides a set of compact, high-performance multi-channel electric laoad systems capable of operating in three modes - constant current, cconstant resistance and constant voltage. Adopting the modular (plug-in) design, the Series consists of four models - two frame models and two load unit models. The PLZ-30F frame can configure the load units up to three channels, and the PLZ-50F frame can configure up to five channels. Two load unit models are available, the PLZ-70UA (75-watt load that operates even at 0 V) and PLZ-150U (150-watt load that operates from 1.5 V up). Load units can be operated in parallel to increase the current capacity or power capacity. By combining different models of load units and frame, the power capacity can be changed from 75 W to 750 W (when five PLZ150U units are mounted in a PLZ-50F-frame). Supporting the GPIB and RS-232C interfaces as standard, the electronic load can be built into various types of test systems, making it useful in testing fuel cells, secondary cells, DC/DC converters, switching power supplies, multiple-output power supplies and more. Both interfaces support IEEE 488.2 as well as the Standard Commands for Programmable Instruments (SCPI) commands, developed for testing and measuring instruments. |
|
| Download datasheet |
PLZ150U
| Manufacturer | Kikusui |
| Power | 150.00 W |
| Package | 3U |
| Available DC input range | 1.5-150 |
PLZ150U
| Manufacturer |
|
| Power | 150.00 W |
| Package | 3U |
| Input voltage | 90-250 Vac 1-phase |
| Efficiency | 0.00 |
| Available DC input range | 1.5-150 |
| Max output current | 0.00 |
| Electronic load input rating power | 150.00 |
| Electronic load input rating current | 30 |
| Warranty | 7 year |
| Dimensions | 470x145x460 |
| Weight | 5 |
| Water-cooled option | No |
| Interface options | GPIB option |
Features:
|
|
| Description: The PLZ-U Series provides a set of compact, high-performance multi-channel electric laoad systems capable of operating in three modes - constant current, cconstant resistance and constant voltage. Adopting the modular (plug-in) design, the Series consists of four models - two frame models and two load unit models. The PLZ-30F frame can configure the load units up to three channels, and the PLZ-50F frame can configure up to five channels. Two load unit models are available, the PLZ-70UA (75-watt load that operates even at 0 V) and PLZ-150U (150-watt load that operates from 1.5 V up). Load units can be operated in parallel to increase the current capacity or power capacity. By combining different models of load units and frame, the power capacity can be changed from 75 W to 750 W (when five PLZ150U units are mounted in a PLZ-50F-frame). Supporting the GPIB and RS-232C interfaces as standard, the electronic load can be built into various types of test systems, making it useful in testing fuel cells, secondary cells, DC/DC converters, switching power supplies, multiple-output power supplies and more. Both interfaces support IEEE 488.2 as well as the Standard Commands for Programmable Instruments (SCPI) commands, developed for testing and measuring instruments. |
|
| Download datasheet |
PLZ205W
| Manufacturer | Kikusui |
| Power | 200.00 W |
| Package | 3U |
| Available DC input range | 0.25-150 |
PLZ205W
| Manufacturer |
|
| Power | 200.00 W |
| Package | 3U |
| Input voltage | 90-250 Vac 1-phase |
| Efficiency | 0.00 |
| Available DC input range | 0.25-150 |
| Max output current | 0.00 |
| Electronic load input rating power | 200.00 |
| Electronic load input rating current | 40 |
| Warranty | 1 year |
| Dimensions | 214.5x124x400 |
| Weight | 7 |
| Water-cooled option | No |
| Interface options | GPIB option |
Features:
|
|
| Description: The PLZ-5W series electronic load is the successor of the highly respected PLZ-4W that continues the series tradition of high specification and excellent build quality. New improvements include a userfriendly LCD color display and a wide voltage range from 0.25 V to 150 V. Custom voltage/current profiles can now be programmed using the new ARB funtion, ideal for LED driver and solar panel testing. The PLZ-5W now includes 6 basic modes of operation ( CC, CR, CV, CP, CC+CV & CR+CV) for optimal flexibility in any test facility. The PLZ-5W in now equipped with a high-speed response feature boasting a maximum slew rate of 60 A/u PLZ1205W). Additonal features incluides a soft-start function, variable slew rate, selectable response mode (CV/CR mode), switching function, ABC programmabe memory, 20 user-defined setup configurations, and a sequense function. The high-speed response of the PLZ-5W is ideal for the development and testing of modern day power supplies that require sudden changes in current at high speeds as well as for testing of current clamps and transducers. The PLZ-5W series is availible in 4 standard models which can be incrementally expanded by adding booster units (PLZ2405W) fora maximum of 10.8 kW/2160 A. The PLZ-5W now is equipped with a diverse digital communication interface supporting LAN (LXI) USB, RS232C, analog control, and GPIB as a factory option. |
|
| Download datasheet |
EA-EL 9500-08 DT
| Manufacturer | EA - Elektro-Automatik |
| Power | 400.00 W |
| Package | Bench mount |
| No. of outputs | 1 |
| Available DC input range | 0-500 |
EA-EL 9500-08 DT
| Manufacturer |
|
| Power | 400.00 W |
| Package | Bench mount |
| No. of outputs | 1 |
| Input voltage | 90-264Vac |
| Efficiency | 0.00 |
| Available DC input range | 0-500 |
| Max output current | 0.00 |
| Electronic load input rating power | 300.00 |
| Electronic load input rating current | 0-8 |
| Warranty | 2 years |
| Dimensions | 279 x 103 x 415 mm |
| Weight | 6.5 |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The new series of compact electronic DC loads, EA-EL 9000 DT series, extends the EA-EL 9000 B series by 10 models to complete the portfolio. It offers new voltage, current and power ratings for a multitude of appliocations for daily use in laboratories, schools or workshops. All models support the four regulation modes constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The core of the control circuit is a fast microprocessor which provides features such as true function generator with common functions like sine wave, rectangle or triangle, but also an arbitrary function. The large colour TFT touch panel offers an intuitive manual operation. |
|
| Download datasheet |
EA-EL 9750-05 DT
| Manufacturer | EA - Elektro-Automatik |
| Power | 400.00 W |
| Package | Bench mount |
| No. of outputs | 1 |
| Available DC input range | 0-750 |
EA-EL 9750-05 DT
| Manufacturer |
|
| Power | 400.00 W |
| Package | Bench mount |
| No. of outputs | 1 |
| Input voltage | 90-264Vac |
| Efficiency | 0.00 |
| Available DC input range | 0-750 |
| Max output current | 0.00 |
| Electronic load input rating power | 300.00 |
| Electronic load input rating current | 0-5 |
| Warranty | 2 years |
| Dimensions | 280 x 103 x 415 mm |
| Weight | 6.5 |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The new series of compact electronic DC loads, EA-EL 9000 DT series, extends the EA-EL 9000 B series by 10 models to complete the portfolio. It offers new voltage, current and power ratings for a multitude of appliocations for daily use in laboratories, schools or workshops. All models support the four regulation modes constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The core of the control circuit is a fast microprocessor which provides features such as true function generator with common functions like sine wave, rectangle or triangle, but also an arbitrary function. The large colour TFT touch panel offers an intuitive manual operation. |
|
| Download datasheet |
PLZ405W
| Manufacturer | Kikusui |
| Power | 400.00 W |
| Package | 3U |
| Available DC input range | 0.25-150 |
PLZ405W
| Manufacturer |
|
| Power | 400.00 W |
| Package | 3U |
| Input voltage | 90-250 Vac 1-phase |
| Efficiency | 0.00 |
| Available DC input range | 0.25-150 |
| Max output current | 0.00 |
| Electronic load input rating power | 400.00 |
| Electronic load input rating current | 80 |
| Warranty | 1 year |
| Dimensions | 214.5x124x400 |
| Weight | 7.5 |
| Water-cooled option | No |
| Interface options | GPIB option |
Features:
|
|
| Description: The PLZ-5W series electronic load is the successor of the highly respected PLZ-4W that continues the series tradition of high specification and excellent build quality. New improvements include a userfriendly LCD color display and a wide voltage range from 0.25 V to 150 V. Custom voltage/current profiles can now be programmed using the new ARB funtion, ideal for LED driver and solar panel testing. The PLZ-5W now includes 6 basic modes of operation ( CC, CR, CV, CP, CC+CV & CR+CV) for optimal flexibility in any test facility. The PLZ-5W in now equipped with a high-speed response feature boasting a maximum slew rate of 60 A/u PLZ1205W). Additonal features incluides a soft-start function, variable slew rate, selectable response mode (CV/CR mode), switching function, ABC programmabe memory, 20 user-defined setup configurations, and a sequense function. The high-speed response of the PLZ-5W is ideal for the development and testing of modern day power supplies that require sudden changes in current at high speeds as well as for testing of current clamps and transducers. The PLZ-5W series is availible in 4 standard models which can be incrementally expanded by adding booster units (PLZ2405W) fora maximum of 10.8 kW/2160 A. The PLZ-5W now is equipped with a diverse digital communication interface supporting LAN (LXI) USB, RS232C, analog control, and GPIB as a factory option. |
|
| Download datasheet |
EA-EL 9360-10 DT
| Manufacturer | EA - Elektro-Automatik |
| Power | 450.00 W |
| Package | Bench mount |
| No. of outputs | 1 |
| Available DC input range | 0-360 |
EA-EL 9360-10 DT
| Manufacturer |
|
| Power | 450.00 W |
| Package | Bench mount |
| No. of outputs | 1 |
| Input voltage | 90-264Vac |
| Efficiency | 0.00 |
| Available DC input range | 0-360 |
| Max output current | 0.00 |
| Electronic load input rating power | 300.00 |
| Electronic load input rating current | 0-10 |
| Warranty | 2 years |
| Dimensions | 278 x 103 x 415 mm |
| Weight | 6.5 |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The new series of compact electronic DC loads, EA-EL 9000 DT series, extends the EA-EL 9000 B series by 10 models to complete the portfolio. It offers new voltage, current and power ratings for a multitude of appliocations for daily use in laboratories, schools or workshops. All models support the four regulation modes constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The core of the control circuit is a fast microprocessor which provides features such as true function generator with common functions like sine wave, rectangle or triangle, but also an arbitrary function. The large colour TFT touch panel offers an intuitive manual operation. |
|
| Download datasheet |
EA-EL 9200-18 DT
| Manufacturer | EA - Elektro-Automatik |
| Power | 500.00 W |
| Package | Bench mount |
| No. of outputs | 1 |
| Available DC input range | 0-200 |
EA-EL 9200-18 DT
| Manufacturer |
|
| Power | 500.00 W |
| Package | Bench mount |
| No. of outputs | 1 |
| Input voltage | 90-264Vac |
| Efficiency | 0.00 |
| Available DC input range | 0-200 |
| Max output current | 0.00 |
| Electronic load input rating power | 300.00 |
| Electronic load input rating current | 0-18 |
| Warranty | 2 years |
| Dimensions | 277 x 103 x 415 mm |
| Weight | 6.5 |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The new series of compact electronic DC loads, EA-EL 9000 DT series, extends the EA-EL 9000 B series by 10 models to complete the portfolio. It offers new voltage, current and power ratings for a multitude of appliocations for daily use in laboratories, schools or workshops. All models support the four regulation modes constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The core of the control circuit is a fast microprocessor which provides features such as true function generator with common functions like sine wave, rectangle or triangle, but also an arbitrary function. The large colour TFT touch panel offers an intuitive manual operation. |
|
| Download datasheet |
EA-EL 9080-45 DT
| Manufacturer | EA - Elektro-Automatik |
| Power | 600.00 W |
| Package | Bench mount |
| No. of outputs | 1 |
| Available DC input range | 0-80 |
EA-EL 9080-45 DT
| Manufacturer |
|
| Power | 600.00 W |
| Package | Bench mount |
| No. of outputs | 1 |
| Input voltage | 90-264Vac |
| Efficiency | 0.00 |
| Available DC input range | 0-80 |
| Max output current | 0.00 |
| Electronic load input rating power | 300.00 |
| Electronic load input rating current | 0-45 |
| Warranty | 2 years |
| Dimensions | 276 x 103 x 415 mm |
| Weight | 6.5 |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The new series of compact electronic DC loads, EA-EL 9000 DT series, extends the EA-EL 9000 B series by 10 models to complete the portfolio. It offers new voltage, current and power ratings for a multitude of appliocations for daily use in laboratories, schools or workshops. All models support the four regulation modes constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The core of the control circuit is a fast microprocessor which provides features such as true function generator with common functions like sine wave, rectangle or triangle, but also an arbitrary function. The large colour TFT touch panel offers an intuitive manual operation. |
|
| Download datasheet |
EA-EL 9500-16 DT
| Manufacturer | EA - Elektro-Automatik |
| Power | 600.00 W |
| Package | Bench mount |
| No. of outputs | 1 |
| Available DC input range | 0-500 |
EA-EL 9500-16 DT
| Manufacturer |
|
| Power | 600.00 W |
| Package | Bench mount |
| No. of outputs | 1 |
| Input voltage | 90-264Vac |
| Efficiency | 0.00 |
| Available DC input range | 0-500 |
| Max output current | 0.00 |
| Electronic load input rating power | 600.00 |
| Electronic load input rating current | 0-16 |
| Warranty | 2 years |
| Dimensions | 284 x 103 x 415 mm |
| Weight | 7.5 |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The new series of compact electronic DC loads, EA-EL 9000 DT series, extends the EA-EL 9000 B series by 10 models to complete the portfolio. It offers new voltage, current and power ratings for a multitude of appliocations for daily use in laboratories, schools or workshops. All models support the four regulation modes constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The core of the control circuit is a fast microprocessor which provides features such as true function generator with common functions like sine wave, rectangle or triangle, but also an arbitrary function. The large colour TFT touch panel offers an intuitive manual operation. |
|
| Download datasheet |
EA-EL 9750-10 DT
| Manufacturer | EA - Elektro-Automatik |
| Power | 600.00 W |
| Package | Bench mount |
| No. of outputs | 1 |
| Available DC input range | 0-750 |
EA-EL 9750-10 DT
| Manufacturer |
|
| Power | 600.00 W |
| Package | Bench mount |
| No. of outputs | 1 |
| Input voltage | 90-264Vac |
| Efficiency | 0.00 |
| Available DC input range | 0-750 |
| Max output current | 0.00 |
| Electronic load input rating power | 600.00 |
| Electronic load input rating current | 0-10 |
| Warranty | 2 years |
| Dimensions | 285 x 103 x 415 mm |
| Weight | 7.5 |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The new series of compact electronic DC loads, EA-EL 9000 DT series, extends the EA-EL 9000 B series by 10 models to complete the portfolio. It offers new voltage, current and power ratings for a multitude of appliocations for daily use in laboratories, schools or workshops. All models support the four regulation modes constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The core of the control circuit is a fast microprocessor which provides features such as true function generator with common functions like sine wave, rectangle or triangle, but also an arbitrary function. The large colour TFT touch panel offers an intuitive manual operation. |
|
| Download datasheet |
EA-EL 9360-20 DT
| Manufacturer | EA - Elektro-Automatik |
| Power | 900.00 W |
| Package | Bench mount |
| No. of outputs | 1 |
| Available DC input range | 0-360 |
EA-EL 9360-20 DT
| Manufacturer |
|
| Power | 900.00 W |
| Package | Bench mount |
| No. of outputs | 1 |
| Input voltage | 90-264Vac |
| Efficiency | 0.00 |
| Available DC input range | 0-360 |
| Max output current | 0.00 |
| Electronic load input rating power | 600.00 |
| Electronic load input rating current | 0-20 |
| Warranty | 2 years |
| Dimensions | 283 x 103 x 415 mm |
| Weight | 7.5 |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The new series of compact electronic DC loads, EA-EL 9000 DT series, extends the EA-EL 9000 B series by 10 models to complete the portfolio. It offers new voltage, current and power ratings for a multitude of appliocations for daily use in laboratories, schools or workshops. All models support the four regulation modes constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The core of the control circuit is a fast microprocessor which provides features such as true function generator with common functions like sine wave, rectangle or triangle, but also an arbitrary function. The large colour TFT touch panel offers an intuitive manual operation. |
|
| Download datasheet |
EA-EL 9200-36 DT
| Manufacturer | EA - Elektro-Automatik |
| Power | 1000.00 W |
| Package | Bench mount |
| No. of outputs | 1 |
| Available DC input range | 0-200 |
EA-EL 9200-36 DT
| Manufacturer |
|
| Power | 1000.00 W |
| Package | Bench mount |
| No. of outputs | 1 |
| Input voltage | 90-264Vac |
| Efficiency | 0.00 |
| Available DC input range | 0-200 |
| Max output current | 0.00 |
| Electronic load input rating power | 600.00 |
| Electronic load input rating current | 0-36 |
| Warranty | 2 years |
| Dimensions | 282 x 103 x 415 mm |
| Weight | 7.5 |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The new series of compact electronic DC loads, EA-EL 9000 DT series, extends the EA-EL 9000 B series by 10 models to complete the portfolio. It offers new voltage, current and power ratings for a multitude of appliocations for daily use in laboratories, schools or workshops. All models support the four regulation modes constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The core of the control circuit is a fast microprocessor which provides features such as true function generator with common functions like sine wave, rectangle or triangle, but also an arbitrary function. The large colour TFT touch panel offers an intuitive manual operation. |
|
| Download datasheet |
PLZ1005WH2
| Manufacturer | Kikusui |
| Power | 1000.00 W |
| Package | 3U |
| Available DC input range | 10-1000 |
PLZ1005WH2
| Manufacturer |
|
| Power | 1000.00 W |
| Package | 3U |
| Input voltage | 90-250 Vac 1-phase |
| Efficiency | 0.00 |
| Available DC input range | 10-1000 |
| Max output current | 0.00 |
| Electronic load input rating power | 1000.00 |
| Electronic load input rating current | 20 |
| Warranty | 1 year |
| Dimensions | 429.5x128x400 |
| Weight | 13 |
| Water-cooled option | No |
| Interface options | GPIB option |
Features:
|
|
| Description: The PLZ-5WH2 high power DC electronic load series is where durable, reliable ingenuity meets a multifunctional, high power design. Providing 5 varietes of power range line-ups, from 1 kW a bench top style model to high power model that can sink uo to 20 kW of power in a single unit. Possitble you can select the optimal capacity according to the load. Load simulation can be achieved faster than ever before thanks to the reliable, high speed design of the PLZ-5HW current control units. Accurate current measurements can be made with an extremely high-setting resolution. A color LCD display allows for highly visible, user-friendly front panel operation. RS232C,, USB and LAN digital interfaces are included as standard for simple intergration into any system. |
|
| Download datasheet |
EA-EL 9080-60 DT
| Manufacturer | EA - Elektro-Automatik |
| Power | 1200.00 W |
| Package | Bench mount |
| No. of outputs | 1 |
| Available DC input range | 0-80 |
EA-EL 9080-60 DT
| Manufacturer |
|
| Power | 1200.00 W |
| Package | Bench mount |
| No. of outputs | 1 |
| Input voltage | 90-264Vac |
| Efficiency | 0.00 |
| Available DC input range | 0-80 |
| Max output current | 0.00 |
| Electronic load input rating power | 600.00 |
| Electronic load input rating current | 0-60 |
| Warranty | 2 years |
| Dimensions | 281 x 103 x 415 mm |
| Weight | 7.5 |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The new series of compact electronic DC loads, EA-EL 9000 DT series, extends the EA-EL 9000 B series by 10 models to complete the portfolio. It offers new voltage, current and power ratings for a multitude of appliocations for daily use in laboratories, schools or workshops. All models support the four regulation modes constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The core of the control circuit is a fast microprocessor which provides features such as true function generator with common functions like sine wave, rectangle or triangle, but also an arbitrary function. The large colour TFT touch panel offers an intuitive manual operation. |
|
| Download datasheet |
EA-EL 9500-30 B 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 1200.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-500 |
EA-EL 9500-30 B 3U
| Manufacturer |
|
| Power | 1200.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 90-264Vac |
| Efficiency | 0.00 |
| Available DC input range | 0-500 |
| Max output current | 0.00 |
| Electronic load input rating power | 1200.00 |
| Electronic load input rating current | 0-30 |
| Warranty | 2 years |
| Weight | 9 |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The new series of compact electronic DC loads, called EA-EL 9000 B replaces the former series EA-EL 9000 A and offers new voltage, current and power ratings for a multitude of applications. All models support the four common regulation modes, constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The FGPA based control circuit provides features such as a function generator with a table based function for the simulation of nonlinear internal resistances. |
|
| Download datasheet |
EA-EL 9750-20 B 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 1200.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-750 |
EA-EL 9750-20 B 3U
| Manufacturer |
|
| Power | 1200.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 90-264Vac |
| Efficiency | 0.00 |
| Available DC input range | 0-750 |
| Max output current | 0.00 |
| Electronic load input rating power | 1200.00 |
| Electronic load input rating current | 0-20 |
| Warranty | 2 years |
| Weight | 9 |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The new series of compact electronic DC loads, called EA-EL 9000 B replaces the former series EA-EL 9000 A and offers new voltage, current and power ratings for a multitude of applications. All models support the four common regulation modes, constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The FGPA based control circuit provides features such as a function generator with a table based function for the simulation of nonlinear internal resistances. |
|
| Download datasheet |
PLZ1205W
| Manufacturer | Kikusui |
| Power | 1200.00 W |
| Package | 3U |
| Available DC input range | 0.25-150 |
PLZ1205W
| Manufacturer |
|
| Power | 1200.00 W |
| Package | 3U |
| Input voltage | 90-250 Vac 1-phase |
| Efficiency | 0.00 |
| Available DC input range | 0.25-150 |
| Max output current | 0.00 |
| Electronic load input rating power | 1200.00 |
| Electronic load input rating current | 240 |
| Warranty | 1 year |
| Dimensions | 429.5x128x400 |
| Weight | 14 |
| Water-cooled option | No |
| Interface options | GPIB option |
Features:
|
|
| Description: The PLZ-5W series electronic load is the successor of the highly respected PLZ-4W that continues the series tradition of high specification and excellent build quality. New improvements include a userfriendly LCD color display and a wide voltage range from 0.25 V to 150 V. Custom voltage/current profiles can now be programmed using the new ARB funtion, ideal for LED driver and solar panel testing. The PLZ-5W now includes 6 basic modes of operation ( CC, CR, CV, CP, CC+CV & CR+CV) for optimal flexibility in any test facility. The PLZ-5W in now equipped with a high-speed response feature boasting a maximum slew rate of 60 A/u PLZ1205W). Additonal features incluides a soft-start function, variable slew rate, selectable response mode (CV/CR mode), switching function, ABC programmabe memory, 20 user-defined setup configurations, and a sequense function. The high-speed response of the PLZ-5W is ideal for the development and testing of modern day power supplies that require sudden changes in current at high speeds as well as for testing of current clamps and transducers. The PLZ-5W series is availible in 4 standard models which can be incrementally expanded by adding booster units (PLZ2405W) fora maximum of 10.8 kW/2160 A. The PLZ-5W now is equipped with a diverse digital communication interface supporting LAN (LXI) USB, RS232C, analog control, and GPIB as a factory option. |
|
| Download datasheet |
EA-ELR 10080-60 2U
| Manufacturer | EA - Elektro-Automatik |
| Power | 1500.00 W |
| Package | 2U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-80 |
EA-ELR 10080-60 2U
| Manufacturer |
|
| Power | 1500.00 W |
| Package | 2U Rack mount |
| No. of outputs | 1 |
| Input voltage | 110-240Vac ±10% single-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-80 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-60 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 10200-25 2U
| Manufacturer | EA - Elektro-Automatik |
| Power | 1500.00 W |
| Package | 2U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-200 |
EA-ELR 10200-25 2U
| Manufacturer |
|
| Power | 1500.00 W |
| Package | 2U Rack mount |
| No. of outputs | 1 |
| Input voltage | 110-240Vac ±10% single-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-200 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-25 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 10360-15 2U
| Manufacturer | EA - Elektro-Automatik |
| Power | 1500.00 W |
| Package | 2U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-360 |
EA-ELR 10360-15 2U
| Manufacturer |
|
| Power | 1500.00 W |
| Package | 2U Rack mount |
| No. of outputs | 1 |
| Input voltage | 110-240Vac ±10% single-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-360 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-15 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 10500-10 2U
| Manufacturer | EA - Elektro-Automatik |
| Power | 1500.00 W |
| Package | 2U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-500 |
EA-ELR 10500-10 2U
| Manufacturer |
|
| Power | 1500.00 W |
| Package | 2U Rack mount |
| No. of outputs | 1 |
| Input voltage | 110-240Vac ±10% single-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-500 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-10 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 10750-06 2U
| Manufacturer | EA - Elektro-Automatik |
| Power | 1500.00 W |
| Package | 2U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-750 |
EA-ELR 10750-06 2U
| Manufacturer |
|
| Power | 1500.00 W |
| Package | 2U Rack mount |
| No. of outputs | 1 |
| Input voltage | 110-240Vac ±10% single-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-750 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-6 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-EL 9360-40 B 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 1800.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-360 |
EA-EL 9360-40 B 3U
| Manufacturer |
|
| Power | 1800.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 90-264Vac |
| Efficiency | 0.00 |
| Available DC input range | 0-360 |
| Max output current | 0.00 |
| Electronic load input rating power | 1500.00 |
| Electronic load input rating current | 0-40 |
| Warranty | 2 years |
| Weight | 9 |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The new series of compact electronic DC loads, called EA-EL 9000 B replaces the former series EA-EL 9000 A and offers new voltage, current and power ratings for a multitude of applications. All models support the four common regulation modes, constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The FGPA based control circuit provides features such as a function generator with a table based function for the simulation of nonlinear internal resistances. |
|
| Download datasheet |
EA-EL 9200-70 B 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 2000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-200 |
EA-EL 9200-70 B 3U
| Manufacturer |
|
| Power | 2000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 90-264Vac |
| Efficiency | 0.00 |
| Available DC input range | 0-200 |
| Max output current | 0.00 |
| Electronic load input rating power | 1500.00 |
| Electronic load input rating current | 0-70 |
| Warranty | 2 years |
| Weight | 9 |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The new series of compact electronic DC loads, called EA-EL 9000 B replaces the former series EA-EL 9000 A and offers new voltage, current and power ratings for a multitude of applications. All models support the four common regulation modes, constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The FGPA based control circuit provides features such as a function generator with a table based function for the simulation of nonlinear internal resistances. |
|
| Download datasheet |
PLZ2005WH2
| Manufacturer | Kikusui |
| Power | 2000.00 W |
| Package | 3U |
| Available DC input range | 10-1000 |
PLZ2005WH2
| Manufacturer |
|
| Power | 2000.00 W |
| Package | 3U |
| Input voltage | 90-250 Vac 1-phase |
| Efficiency | 0.00 |
| Available DC input range | 10-1000 |
| Max output current | 0.00 |
| Electronic load input rating power | 2000.00 |
| Electronic load input rating current | 40 |
| Warranty | 1 year |
| Dimensions | 429.5x128x400 |
| Weight | 16 |
| Water-cooled option | No |
| Interface options | GPIB option |
Features:
|
|
| Description: The PLZ-5WH2 high power DC electronic load series is where durable, reliable ingenuity meets a multifunctional, high power design. Providing 5 varietes of power range line-ups, from 1 kW a bench top style model to high power model that can sink uo to 20 kW of power in a single unit. Possitble you can select the optimal capacity according to the load. Load simulation can be achieved faster than ever before thanks to the reliable, high speed design of the PLZ-5HW current control units. Accurate current measurements can be made with an extremely high-setting resolution. A color LCD display allows for highly visible, user-friendly front panel operation. RS232C,, USB and LAN digital interfaces are included as standard for simple intergration into any system. |
|
| Download datasheet |
EA-EL 9080-170 B 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 2400.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-80 |
EA-EL 9080-170 B 3U
| Manufacturer |
|
| Power | 2400.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 90-264Vac |
| Efficiency | 0.00 |
| Available DC input range | 0-80 |
| Max output current | 0.00 |
| Electronic load input rating power | 1500.00 |
| Electronic load input rating current | 0-170 |
| Warranty | 2 years |
| Weight | 9 |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The new series of compact electronic DC loads, called EA-EL 9000 B replaces the former series EA-EL 9000 A and offers new voltage, current and power ratings for a multitude of applications. All models support the four common regulation modes, constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The FGPA based control circuit provides features such as a function generator with a table based function for the simulation of nonlinear internal resistances. |
|
| Download datasheet |
EA-EL 9500-60 B 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 2400.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-500 |
EA-EL 9500-60 B 3U
| Manufacturer |
|
| Power | 2400.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 90-264Vac |
| Efficiency | 0.00 |
| Available DC input range | 0-500 |
| Max output current | 0.00 |
| Electronic load input rating power | 2400.00 |
| Electronic load input rating current | 0-60 |
| Warranty | 2 years |
| Weight | 13 |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The new series of compact electronic DC loads, called EA-EL 9000 B replaces the former series EA-EL 9000 A and offers new voltage, current and power ratings for a multitude of applications. All models support the four common regulation modes, constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The FGPA based control circuit provides features such as a function generator with a table based function for the simulation of nonlinear internal resistances. |
|
| Download datasheet |
EA-EL 9750-40 B 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 2400.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-750 |
EA-EL 9750-40 B 3U
| Manufacturer |
|
| Power | 2400.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 90-264Vac |
| Efficiency | 0.00 |
| Available DC input range | 0-750 |
| Max output current | 0.00 |
| Electronic load input rating power | 2400.00 |
| Electronic load input rating current | 0-40 |
| Warranty | 2 years |
| Weight | 13 |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The new series of compact electronic DC loads, called EA-EL 9000 B replaces the former series EA-EL 9000 A and offers new voltage, current and power ratings for a multitude of applications. All models support the four common regulation modes, constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The FGPA based control circuit provides features such as a function generator with a table based function for the simulation of nonlinear internal resistances. |
|
| Download datasheet |
PLZ2405WB
| Manufacturer | Kikusui |
| Power | 2400.00 W |
| Package | 2U |
| Available DC input range | 0.25-150 |
PLZ2405WB
| Manufacturer |
|
| Power | 2400.00 W |
| Package | 2U |
| Input voltage | 90-250 Vac 1-phase |
| Efficiency | 0.00 |
| Available DC input range | 0.25-150 |
| Max output current | 0.00 |
| Electronic load input rating power | 2400.00 |
| Electronic load input rating current | 480 |
| Warranty | 1 year |
| Dimensions | 430x86x450 |
| Weight | 15 |
| Water-cooled option | No |
| Interface options | GPIB option |
Features:
|
|
| Description: The PLZ-5W series electronic load is the successor of the highly respected PLZ-4W that continues the series tradition of high specification and excellent build quality. New improvements include a userfriendly LCD color display and a wide voltage range from 0.25 V to 150 V. Custom voltage/current profiles can now be programmed using the new ARB funtion, ideal for LED driver and solar panel testing. The PLZ-5W now includes 6 basic modes of operation ( CC, CR, CV, CP, CC+CV & CR+CV) for optimal flexibility in any test facility. The PLZ-5W in now equipped with a high-speed response feature boasting a maximum slew rate of 60 A/u PLZ1205W). Additonal features incluides a soft-start function, variable slew rate, selectable response mode (CV/CR mode), switching function, ABC programmabe memory, 20 user-defined setup configurations, and a sequense function. The high-speed response of the PLZ-5W is ideal for the development and testing of modern day power supplies that require sudden changes in current at high speeds as well as for testing of current clamps and transducers. The PLZ-5W series is availible in 4 standard models which can be incrementally expanded by adding booster units (PLZ2405W) fora maximum of 10.8 kW/2160 A. The PLZ-5W now is equipped with a diverse digital communication interface supporting LAN (LXI) USB, RS232C, analog control, and GPIB as a factory option. |
|
| Download datasheet |
EA-ELR 10080-120 2U
| Manufacturer | EA - Elektro-Automatik |
| Power | 3000.00 W |
| Package | 2U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-80 |
EA-ELR 10080-120 2U
| Manufacturer |
|
| Power | 3000.00 W |
| Package | 2U Rack mount |
| No. of outputs | 1 |
| Input voltage | 110-240Vac ±10% single-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-80 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-120 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 10200-50 2U
| Manufacturer | EA - Elektro-Automatik |
| Power | 3000.00 W |
| Package | 2U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-200 |
EA-ELR 10200-50 2U
| Manufacturer |
|
| Power | 3000.00 W |
| Package | 2U Rack mount |
| No. of outputs | 1 |
| Input voltage | 110-240Vac ±10% single-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-200 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-50 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 10360-30 2U
| Manufacturer | EA - Elektro-Automatik |
| Power | 3000.00 W |
| Package | 2U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-360 |
EA-ELR 10360-30 2U
| Manufacturer |
|
| Power | 3000.00 W |
| Package | 2U Rack mount |
| No. of outputs | 1 |
| Input voltage | 110-240Vac ±10% single-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-360 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-30 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 10500-20 2U
| Manufacturer | EA - Elektro-Automatik |
| Power | 3000.00 W |
| Package | 2U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-500 |
EA-ELR 10500-20 2U
| Manufacturer |
|
| Power | 3000.00 W |
| Package | 2U Rack mount |
| No. of outputs | 1 |
| Input voltage | 110-240Vac ±10% single-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-500 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-20 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 10750-12 2U
| Manufacturer | EA - Elektro-Automatik |
| Power | 3000.00 W |
| Package | 2U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-750 |
EA-ELR 10750-12 2U
| Manufacturer |
|
| Power | 3000.00 W |
| Package | 2U Rack mount |
| No. of outputs | 1 |
| Input voltage | 110-240Vac ±10% single-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-750 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-12 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 11000-10 2U
| Manufacturer | EA - Elektro-Automatik |
| Power | 3000.00 W |
| Package | 2U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-1000 |
EA-ELR 11000-10 2U
| Manufacturer |
|
| Power | 3000.00 W |
| Package | 2U Rack mount |
| No. of outputs | 1 |
| Input voltage | 110-240Vac ±10% single-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-1000 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-10 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 11500-06 2U
| Manufacturer | EA - Elektro-Automatik |
| Power | 3000.00 W |
| Package | 2U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-1500 |
EA-ELR 11500-06 2U
| Manufacturer |
|
| Power | 3000.00 W |
| Package | 2U Rack mount |
| No. of outputs | 1 |
| Input voltage | 110-240Vac ±10% single-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-1500 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-6 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-EL 9360-80 B 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 3600.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-360 |
EA-EL 9360-80 B 3U
| Manufacturer |
|
| Power | 3600.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 90-264Vac |
| Efficiency | 0.00 |
| Available DC input range | 0-360 |
| Max output current | 0.00 |
| Electronic load input rating power | 3000.00 |
| Electronic load input rating current | 0-80 |
| Warranty | 2 years |
| Weight | 13 |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The new series of compact electronic DC loads, called EA-EL 9000 B replaces the former series EA-EL 9000 A and offers new voltage, current and power ratings for a multitude of applications. All models support the four common regulation modes, constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The FGPA based control circuit provides features such as a function generator with a table based function for the simulation of nonlinear internal resistances. |
|
| Download datasheet |
EA-EL 9500-90 B 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 3600.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-500 |
EA-EL 9500-90 B 3U
| Manufacturer |
|
| Power | 3600.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 90-264Vac |
| Efficiency | 0.00 |
| Available DC input range | 0-500 |
| Max output current | 0.00 |
| Electronic load input rating power | 3600.00 |
| Electronic load input rating current | 0-90 |
| Warranty | 2 years |
| Weight | 17 |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The new series of compact electronic DC loads, called EA-EL 9000 B replaces the former series EA-EL 9000 A and offers new voltage, current and power ratings for a multitude of applications. All models support the four common regulation modes, constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The FGPA based control circuit provides features such as a function generator with a table based function for the simulation of nonlinear internal resistances. |
|
| Download datasheet |
EA-EL 9750-60 B 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 3600.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-750 |
EA-EL 9750-60 B 3U
| Manufacturer |
|
| Power | 3600.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 90-264Vac |
| Efficiency | 0.00 |
| Available DC input range | 0-750 |
| Max output current | 0.00 |
| Electronic load input rating power | 3600.00 |
| Electronic load input rating current | 0-60 |
| Warranty | 2 years |
| Weight | 17 |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The new series of compact electronic DC loads, called EA-EL 9000 B replaces the former series EA-EL 9000 A and offers new voltage, current and power ratings for a multitude of applications. All models support the four common regulation modes, constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The FGPA based control circuit provides features such as a function generator with a table based function for the simulation of nonlinear internal resistances. |
|
| Download datasheet |
EA-EL 9200-140 B 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 4000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-200 |
EA-EL 9200-140 B 3U
| Manufacturer |
|
| Power | 4000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 90-264Vac |
| Efficiency | 0.00 |
| Available DC input range | 0-200 |
| Max output current | 0.00 |
| Electronic load input rating power | 3000.00 |
| Electronic load input rating current | 0-140 |
| Warranty | 2 years |
| Weight | 13 |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The new series of compact electronic DC loads, called EA-EL 9000 B replaces the former series EA-EL 9000 A and offers new voltage, current and power ratings for a multitude of applications. All models support the four common regulation modes, constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The FGPA based control circuit provides features such as a function generator with a table based function for the simulation of nonlinear internal resistances. |
|
| Download datasheet |
PLZ4005WH2
| Manufacturer | Kikusui |
| Power | 4000.00 W |
| Package | 3U |
| Available DC input range | 10-1000 |
PLZ4005WH2
| Manufacturer |
|
| Power | 4000.00 W |
| Package | 3U |
| Input voltage | 90-250 Vac 1-phase |
| Efficiency | 0.00 |
| Available DC input range | 10-1000 |
| Max output current | 0.00 |
| Electronic load input rating power | 4000.00 |
| Electronic load input rating current | 80 |
| Warranty | 1 year |
| Dimensions | 429.5x128x500 |
| Weight | 20 |
| Water-cooled option | No |
| Interface options | GPIB option |
Features:
|
|
| Description: The PLZ-5WH2 high power DC electronic load series is where durable, reliable ingenuity meets a multifunctional, high power design. Providing 5 varietes of power range line-ups, from 1 kW a bench top style model to high power model that can sink uo to 20 kW of power in a single unit. Possitble you can select the optimal capacity according to the load. Load simulation can be achieved faster than ever before thanks to the reliable, high speed design of the PLZ-5HW current control units. Accurate current measurements can be made with an extremely high-setting resolution. A color LCD display allows for highly visible, user-friendly front panel operation. RS232C,, USB and LAN digital interfaces are included as standard for simple intergration into any system. |
|
| Download datasheet |
EA-EL 9080-340 B 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 4800.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-80 |
EA-EL 9080-340 B 3U
| Manufacturer |
|
| Power | 4800.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 90-264Vac |
| Efficiency | 0.00 |
| Available DC input range | 0-80 |
| Max output current | 0.00 |
| Electronic load input rating power | 3000.00 |
| Electronic load input rating current | 0-340 |
| Warranty | 2 years |
| Weight | 13 |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The new series of compact electronic DC loads, called EA-EL 9000 B replaces the former series EA-EL 9000 A and offers new voltage, current and power ratings for a multitude of applications. All models support the four common regulation modes, constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The FGPA based control circuit provides features such as a function generator with a table based function for the simulation of nonlinear internal resistances. |
|
| Download datasheet |
EA-ELR 10080-170 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 5000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-80 |
EA-ELR 10080-170 3U
| Manufacturer |
|
| Power | 5000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-80 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-170 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 10200-70 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 5000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-200 |
EA-ELR 10200-70 3U
| Manufacturer |
|
| Power | 5000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-200 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-70 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 10360-40 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 5000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-360 |
EA-ELR 10360-40 3U
| Manufacturer |
|
| Power | 5000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-360 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-40 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 10500-30 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 5000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-500 |
EA-ELR 10500-30 3U
| Manufacturer |
|
| Power | 5000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-500 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-30 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 10750-20 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 5000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-750 |
EA-ELR 10750-20 3U
| Manufacturer |
|
| Power | 5000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-750 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-20 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-EL 9360-120 B 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 5400.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-360 |
EA-EL 9360-120 B 3U
| Manufacturer |
|
| Power | 5400.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 90-264Vac |
| Efficiency | 0.00 |
| Available DC input range | 0-360 |
| Max output current | 0.00 |
| Electronic load input rating power | 4500.00 |
| Electronic load input rating current | 0-120 |
| Warranty | 2 years |
| Weight | 17 |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The new series of compact electronic DC loads, called EA-EL 9000 B replaces the former series EA-EL 9000 A and offers new voltage, current and power ratings for a multitude of applications. All models support the four common regulation modes, constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The FGPA based control circuit provides features such as a function generator with a table based function for the simulation of nonlinear internal resistances. |
|
| Download datasheet |
EA-EL 9200-210 B 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 6000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-200 |
EA-EL 9200-210 B 3U
| Manufacturer |
|
| Power | 6000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 90-264Vac |
| Efficiency | 0.00 |
| Available DC input range | 0-200 |
| Max output current | 0.00 |
| Electronic load input rating power | 4500.00 |
| Electronic load input rating current | 0-210 |
| Warranty | 2 years |
| Weight | 17 |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The new series of compact electronic DC loads, called EA-EL 9000 B replaces the former series EA-EL 9000 A and offers new voltage, current and power ratings for a multitude of applications. All models support the four common regulation modes, constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The FGPA based control circuit provides features such as a function generator with a table based function for the simulation of nonlinear internal resistances. |
|
| Download datasheet |
EA-EL 9080-510 B 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 7200.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-80 |
EA-EL 9080-510 B 3U
| Manufacturer |
|
| Power | 7200.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 90-264Vac |
| Efficiency | 0.00 |
| Available DC input range | 0-80 |
| Max output current | 0.00 |
| Electronic load input rating power | 4500.00 |
| Electronic load input rating current | 0-510 |
| Warranty | 2 years |
| Weight | 17 |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The new series of compact electronic DC loads, called EA-EL 9000 B replaces the former series EA-EL 9000 A and offers new voltage, current and power ratings for a multitude of applications. All models support the four common regulation modes, constant voltage (CV), constant current (CC), constant power (CP) and constant resistance (CR). The FGPA based control circuit provides features such as a function generator with a table based function for the simulation of nonlinear internal resistances. |
|
| Download datasheet |
EA-ELR 10080-340 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 10000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-80 |
EA-ELR 10080-340 3U
| Manufacturer |
|
| Power | 10000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-80 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-340 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 10200-140 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 10000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-200 |
EA-ELR 10200-140 3U
| Manufacturer |
|
| Power | 10000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-200 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-140 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 10360-80 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 10000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-360 |
EA-ELR 10360-80 3U
| Manufacturer |
|
| Power | 10000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-360 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-80 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 10500-60 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 10000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-500 |
EA-ELR 10500-60 3U
| Manufacturer |
|
| Power | 10000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-500 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-60 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 10750-40 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 10000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-750 |
EA-ELR 10750-40 3U
| Manufacturer |
|
| Power | 10000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-750 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-40 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 11000-30 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 10000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-1000 |
EA-ELR 11000-30 3U
| Manufacturer |
|
| Power | 10000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-1000 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-30 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 11500-20 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 10000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-1500 |
EA-ELR 11500-20 3U
| Manufacturer |
|
| Power | 10000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-1500 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-20 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
PLZ12005WH2
| Manufacturer | Kikusui |
| Power | 12000.00 W |
| Package | 9U |
| Available DC input range | 10-1000 |
PLZ12005WH2
| Manufacturer |
|
| Power | 12000.00 W |
| Package | 9U |
| Input voltage | 90-250 Vac 1-phase |
| Efficiency | 0.00 |
| Available DC input range | 10-1000 |
| Max output current | 0.00 |
| Electronic load input rating power | 12000.00 |
| Electronic load input rating current | 240 |
| Warranty | 1 year |
| Dimensions | 430x396.2x550 |
| Weight | 64 |
| Water-cooled option | No |
| Interface options | GPIB option |
Features:
|
|
| Description: The PLZ-5WH2 high power DC electronic load series is where durable, reliable ingenuity meets a multifunctional, high power design. Providing 5 varietes of power range line-ups, from 1 kW a bench top style model to high power model that can sink uo to 20 kW of power in a single unit. Possitble you can select the optimal capacity according to the load. Load simulation can be achieved faster than ever before thanks to the reliable, high speed design of the PLZ-5HW current control units. Accurate current measurements can be made with an extremely high-setting resolution. A color LCD display allows for highly visible, user-friendly front panel operation. RS232C,, USB and LAN digital interfaces are included as standard for simple intergration into any system. |
|
| Download datasheet |
EA-ELR 10080-510 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 15000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-80 |
EA-ELR 10080-510 3U
| Manufacturer |
|
| Power | 15000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-80 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-510 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 10200-210 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 15000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-200 |
EA-ELR 10200-210 3U
| Manufacturer |
|
| Power | 15000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-200 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-210 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 10360-120 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 15000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-360 |
EA-ELR 10360-120 3U
| Manufacturer |
|
| Power | 15000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-360 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-120 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 10500-90 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 15000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-500 |
EA-ELR 10500-90 3U
| Manufacturer |
|
| Power | 15000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-500 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-90 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 10750-60 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 15000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-750 |
EA-ELR 10750-60 3U
| Manufacturer |
|
| Power | 15000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-750 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-60 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 11000-40 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 15000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-1000 |
EA-ELR 11000-40 3U
| Manufacturer |
|
| Power | 15000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-1000 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-40 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 11500-30 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 15000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-1500 |
EA-ELR 11500-30 3U
| Manufacturer |
|
| Power | 15000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-1500 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-30 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 12000-20 3U
| Manufacturer | EA - Elektro-Automatik |
| Power | 15000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-2000 |
EA-ELR 12000-20 3U
| Manufacturer |
|
| Power | 15000.00 W |
| Package | 3U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-2000 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-20 |
| Warranty | 2 years |
| Water-cooled option | No |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
PLZ20005WH2
| Manufacturer | Kikusui |
| Power | 20000.00 W |
| Package | 13U |
| Available DC input range | 10-1000 |
PLZ20005WH2
| Manufacturer |
|
| Power | 20000.00 W |
| Package | 13U |
| Input voltage | 90-250 Vac 1-phase |
| Efficiency | 0.00 |
| Available DC input range | 10-1000 |
| Max output current | 0.00 |
| Electronic load input rating power | 20000.00 |
| Electronic load input rating current | 400 |
| Warranty | 1 year |
| Dimensions | 430x573.5x550 |
| Weight | 93 |
| Water-cooled option | No |
| Interface options | GPIB option |
Features:
|
|
| Description: The PLZ-5WH2 high power DC electronic load series is where durable, reliable ingenuity meets a multifunctional, high power design. Providing 5 varietes of power range line-ups, from 1 kW a bench top style model to high power model that can sink uo to 20 kW of power in a single unit. Possitble you can select the optimal capacity according to the load. Load simulation can be achieved faster than ever before thanks to the reliable, high speed design of the PLZ-5HW current control units. Accurate current measurements can be made with an extremely high-setting resolution. A color LCD display allows for highly visible, user-friendly front panel operation. RS232C,, USB and LAN digital interfaces are included as standard for simple intergration into any system. |
|
| Download datasheet |
EA-ELR 10080-1000 4U
| Manufacturer | EA - Elektro-Automatik |
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-80 |
EA-ELR 10080-1000 4U
| Manufacturer |
|
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-80 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-1000 |
| Warranty | 2 years |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 10200-420 4U
| Manufacturer | EA - Elektro-Automatik |
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-200 |
EA-ELR 10200-420 4U
| Manufacturer |
|
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-200 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-420 |
| Warranty | 2 years |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 10360-240 4U
| Manufacturer | EA - Elektro-Automatik |
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-360 |
EA-ELR 10360-240 4U
| Manufacturer |
|
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-360 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-240 |
| Warranty | 2 years |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 10500-180 4U
| Manufacturer | EA - Elektro-Automatik |
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-500 |
EA-ELR 10500-180 4U
| Manufacturer |
|
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-500 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-180 |
| Warranty | 2 years |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 10750-120 4U
| Manufacturer | EA - Elektro-Automatik |
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-750 |
EA-ELR 10750-120 4U
| Manufacturer |
|
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-750 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-120 |
| Warranty | 2 years |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 11000-80 4U
| Manufacturer | EA - Elektro-Automatik |
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-1000 |
EA-ELR 11000-80 4U
| Manufacturer |
|
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-1000 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-80 |
| Warranty | 2 years |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 11500-60 4U
| Manufacturer | EA - Elektro-Automatik |
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-1500 |
EA-ELR 11500-60 4U
| Manufacturer |
|
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-1500 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-60 |
| Warranty | 2 years |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-ELR 12000-40 4U
| Manufacturer | EA - Elektro-Automatik |
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-2000 |
EA-ELR 12000-40 4U
| Manufacturer |
|
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.00 |
| Available DC input range | 0-2000 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Electronic load input rating current | 0-40 |
| Warranty | 2 years |
| Water-cooled option | No |
| Manual | Link |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the energy back into the local grid with an efficiency up to over 96%. The ELR 10000 series includes single and three phase units, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltage and current are directed by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 6 A up to 0 - 1000 A in a single device. The DC-Input operates as a flexible input stage with a constant power characteristic (autoranging), and a wide voltage, current and power range. To achieve higher power and current all units are equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 1920 W and 64000 A. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant. In this way a user can construct a 75 kW system from two 30 kW and one 15 kW devices from the ELR 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, assorted interfaces and ports, software solutions and many more functions. |
|
| Download datasheet |
EA-PUL 10080-1000 4U
| Manufacturer | EA - Elektro-Automatik |
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-80 |
EA-PUL 10080-1000 4U
| Manufacturer |
|
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Notes | Water cooling and Integrated function generator options available |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.96 |
| Available DC input range | 0-80 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Warranty | 2 years |
| Dimensions | 19" x 4U x 668 mm |
| Weight | 50kg (56kg with water cooling) |
| Water-cooled option | Yes |
| Interface options | CAN, CANopen, RS232, ModBus, TCP, Profinet, Profibus, EtherCAT, Ethernet |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the consumed DC energy back into the local or public grid with an efficiency up to over 96%. The PUL 10000 series are three phase models, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltages and currents are determined by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 40 A up to 0 - 1000 A in a single device. The DC input operates as a flexible input stage with a constant power characteristic (autoranging) with a wide voltage and current range. To achieve higher power and current all units are equipped with a Master-slave-Bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 3840 W and 64000 A. Such a system works as a single unit and can use different power classes start from 5kW, only the voltage class must remain constant. In this way a user can construct a 150 kW system from two 60 kW and one 30 kW devices from the PUL 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, various optional industrial interfaces, software solutions and many more functions. |
|
| Download datasheet |
EA-PUL 10200-420 4U
| Manufacturer | EA - Elektro-Automatik |
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-200 |
EA-PUL 10200-420 4U
| Manufacturer |
|
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Notes | Water cooling and Integrated function generator options available |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.95 |
| Available DC input range | 0-200 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Warranty | 2 years |
| Dimensions | 19" x 4U x 668 mm |
| Weight | 50kg (56kg with water cooling) |
| Water-cooled option | Yes |
| Interface options | CAN, CANopen, RS232, ModBus, TCP, Profinet, Profibus, EtherCAT, Ethernet |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the consumed DC energy back into the local or public grid with an efficiency up to over 96%. The PUL 10000 series are three phase models, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltages and currents are determined by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 40 A up to 0 - 1000 A in a single device. The DC input operates as a flexible input stage with a constant power characteristic (autoranging) with a wide voltage and current range. To achieve higher power and current all units are equipped with a Master-slave-Bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 3840 W and 64000 A. Such a system works as a single unit and can use different power classes start from 5kW, only the voltage class must remain constant. In this way a user can construct a 150 kW system from two 60 kW and one 30 kW devices from the PUL 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, various optional industrial interfaces, software solutions and many more functions. |
|
| Download datasheet |
EA-PUL 10360-240 4U
| Manufacturer | EA - Elektro-Automatik |
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-360 |
EA-PUL 10360-240 4U
| Manufacturer |
|
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Notes | Water cooling and Integrated function generator options available |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.96 |
| Available DC input range | 0-360 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Warranty | 2 years |
| Dimensions | 19" x 4U x 668 mm |
| Weight | 50kg (56kg with water cooling) |
| Water-cooled option | Yes |
| Interface options | CAN, CANopen, RS232, ModBus, TCP, Profinet, Profibus, EtherCAT, Ethernet |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the consumed DC energy back into the local or public grid with an efficiency up to over 96%. The PUL 10000 series are three phase models, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltages and currents are determined by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 40 A up to 0 - 1000 A in a single device. The DC input operates as a flexible input stage with a constant power characteristic (autoranging) with a wide voltage and current range. To achieve higher power and current all units are equipped with a Master-slave-Bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 3840 W and 64000 A. Such a system works as a single unit and can use different power classes start from 5kW, only the voltage class must remain constant. In this way a user can construct a 150 kW system from two 60 kW and one 30 kW devices from the PUL 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, various optional industrial interfaces, software solutions and many more functions. |
|
| Download datasheet |
EA-PUL 10500-180 4U
| Manufacturer | EA - Elektro-Automatik |
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-500 |
EA-PUL 10500-180 4U
| Manufacturer |
|
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Notes | Water cooling and Integrated function generator options available |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.97 |
| Available DC input range | 0-500 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Warranty | 2 years |
| Dimensions | 19" x 4U x 668 mm |
| Weight | 50kg (56kg with water cooling) |
| Water-cooled option | Yes |
| Interface options | CAN, CANopen, RS232, ModBus, TCP, Profinet, Profibus, EtherCAT, Ethernet |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the consumed DC energy back into the local or public grid with an efficiency up to over 96%. The PUL 10000 series are three phase models, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltages and currents are determined by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 40 A up to 0 - 1000 A in a single device. The DC input operates as a flexible input stage with a constant power characteristic (autoranging) with a wide voltage and current range. To achieve higher power and current all units are equipped with a Master-slave-Bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 3840 W and 64000 A. Such a system works as a single unit and can use different power classes start from 5kW, only the voltage class must remain constant. In this way a user can construct a 150 kW system from two 60 kW and one 30 kW devices from the PUL 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, various optional industrial interfaces, software solutions and many more functions. |
|
| Download datasheet |
EA-PUL 10750-120 4U
| Manufacturer | EA - Elektro-Automatik |
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-750 |
EA-PUL 10750-120 4U
| Manufacturer |
|
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Notes | Water cooling and Integrated function generator options available |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.97 |
| Available DC input range | 0-750 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Warranty | 2 years |
| Dimensions | 19" x 4U x 668 mm |
| Weight | 50kg (56kg with water cooling) |
| Water-cooled option | Yes |
| Interface options | CAN, CANopen, RS232, ModBus, TCP, Profinet, Profibus, EtherCAT, Ethernet |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the consumed DC energy back into the local or public grid with an efficiency up to over 96%. The PUL 10000 series are three phase models, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltages and currents are determined by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 40 A up to 0 - 1000 A in a single device. The DC input operates as a flexible input stage with a constant power characteristic (autoranging) with a wide voltage and current range. To achieve higher power and current all units are equipped with a Master-slave-Bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 3840 W and 64000 A. Such a system works as a single unit and can use different power classes start from 5kW, only the voltage class must remain constant. In this way a user can construct a 150 kW system from two 60 kW and one 30 kW devices from the PUL 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, various optional industrial interfaces, software solutions and many more functions. |
|
| Download datasheet |
EA-PUL 10920-125 4U
| Manufacturer | EA - Elektro-Automatik |
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-920 |
EA-PUL 10920-125 4U
| Manufacturer |
|
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Notes | Water cooling and Integrated function generator options available |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.97 |
| Available DC input range | 0-920 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Warranty | 2 years |
| Dimensions | 19" x 4U x 668 mm |
| Weight | 50kg (56kg with water cooling) |
| Water-cooled option | Yes |
| Interface options | CAN, CANopen, RS232, ModBus, TCP, Profinet, Profibus, EtherCAT, Ethernet |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the consumed DC energy back into the local or public grid with an efficiency up to over 96%. The PUL 10000 series are three phase models, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltages and currents are determined by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 40 A up to 0 - 1000 A in a single device. The DC input operates as a flexible input stage with a constant power characteristic (autoranging) with a wide voltage and current range. To achieve higher power and current all units are equipped with a Master-slave-Bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 3840 W and 64000 A. Such a system works as a single unit and can use different power classes start from 5kW, only the voltage class must remain constant. In this way a user can construct a 150 kW system from two 60 kW and one 30 kW devices from the PUL 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, various optional industrial interfaces, software solutions and many more functions. |
|
| Download datasheet |
EA-PUL 11000-80 4U
| Manufacturer | EA - Elektro-Automatik |
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-1000 |
EA-PUL 11000-80 4U
| Manufacturer |
|
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Notes | Water cooling and Integrated function generator options available |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.96 |
| Available DC input range | 0-1000 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Warranty | 2 years |
| Dimensions | 19" x 4U x 668 mm |
| Weight | 50kg (56kg with water cooling) |
| Water-cooled option | Yes |
| Interface options | CAN, CANopen, RS232, ModBus, TCP, Profinet, Profibus, EtherCAT, Ethernet |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the consumed DC energy back into the local or public grid with an efficiency up to over 96%. The PUL 10000 series are three phase models, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltages and currents are determined by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 40 A up to 0 - 1000 A in a single device. The DC input operates as a flexible input stage with a constant power characteristic (autoranging) with a wide voltage and current range. To achieve higher power and current all units are equipped with a Master-slave-Bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 3840 W and 64000 A. Such a system works as a single unit and can use different power classes start from 5kW, only the voltage class must remain constant. In this way a user can construct a 150 kW system from two 60 kW and one 30 kW devices from the PUL 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, various optional industrial interfaces, software solutions and many more functions. |
|
| Download datasheet |
EA-PUL 11500-60 4U
| Manufacturer | EA - Elektro-Automatik |
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-1500 |
EA-PUL 11500-60 4U
| Manufacturer |
|
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Notes | Water cooling and Integrated function generator options available |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.97 |
| Available DC input range | 0-1500 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Warranty | 2 years |
| Dimensions | 19" x 4U x 668 mm |
| Weight | 50kg (56kg with water cooling) |
| Water-cooled option | Yes |
| Interface options | CAN, CANopen, RS232, ModBus, TCP, Profinet, Profibus, EtherCAT, Ethernet |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the consumed DC energy back into the local or public grid with an efficiency up to over 96%. The PUL 10000 series are three phase models, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltages and currents are determined by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 40 A up to 0 - 1000 A in a single device. The DC input operates as a flexible input stage with a constant power characteristic (autoranging) with a wide voltage and current range. To achieve higher power and current all units are equipped with a Master-slave-Bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 3840 W and 64000 A. Such a system works as a single unit and can use different power classes start from 5kW, only the voltage class must remain constant. In this way a user can construct a 150 kW system from two 60 kW and one 30 kW devices from the PUL 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, various optional industrial interfaces, software solutions and many more functions. |
|
| Download datasheet |
EA-PUL 12000-40 4U
| Manufacturer | EA - Elektro-Automatik |
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Available DC input range | 0-2000 |
EA-PUL 12000-40 4U
| Manufacturer |
|
| Power | 30000.00 W |
| Package | 4U Rack mount |
| No. of outputs | 1 |
| Notes | Water cooling and Integrated function generator options available |
| Input voltage | 208-480Vac ±10% 3-phase |
| Efficiency | 0.97 |
| Available DC input range | 0-2000 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Warranty | 2 years |
| Dimensions | 19" x 4U x 668 mm |
| Weight | 50kg (56kg with water cooling) |
| Water-cooled option | Yes |
| Interface options | CAN, CANopen, RS232, ModBus, TCP, Profinet, Profibus, EtherCAT, Ethernet |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the consumed DC energy back into the local or public grid with an efficiency up to over 96%. The PUL 10000 series are three phase models, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltages and currents are determined by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 40 A up to 0 - 1000 A in a single device. The DC input operates as a flexible input stage with a constant power characteristic (autoranging) with a wide voltage and current range. To achieve higher power and current all units are equipped with a Master-slave-Bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 3840 W and 64000 A. Such a system works as a single unit and can use different power classes start from 5kW, only the voltage class must remain constant. In this way a user can construct a 150 kW system from two 60 kW and one 30 kW devices from the PUL 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, various optional industrial interfaces, software solutions and many more functions. |
|
| Download datasheet |
EA-PUL 10360-480 6U
| Manufacturer | EA - Elektro-Automatik |
| Power | 60000.00 W |
| Package | 6U Rack mount |
| No. of outputs | 1 |
EA-PUL 10360-480 6U
| Manufacturer |
|
| Power | 60000.00 W |
| Package | 6U Rack mount |
| No. of outputs | 1 |
| Notes | Water cooling and Integrated function generator options available |
| Input voltage | 380-480Vac ±10% 3-phase |
| Efficiency | 0.96 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Warranty | 2 years |
| Dimensions | 19" x 6U x 668 mm |
| Weight | 76kg (82kg with water cooling) |
| Water-cooled option | Yes |
| Interface options | CAN, CANopen, RS232, Profibus, EtherCAT, Profinet/Modbus/Ethernet (with 1 or 2 ports) |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the consumed DC energy back into the local or public grid with an efficiency up to over 96%. The PUL 10000 series are three phase models, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltages and currents are determined by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 40 A up to 0 - 1000 A in a single device. The DC input operates as a flexible input stage with a constant power characteristic (autoranging) with a wide voltage and current range. To achieve higher power and current all units are equipped with a Master-slave-Bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 3840 W and 64000 A. Such a system works as a single unit and can use different power classes start from 5kW, only the voltage class must remain constant. In this way a user can construct a 150 kW system from two 60 kW and one 30 kW devices from the PUL 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, various optional industrial interfaces, software solutions and many more functions. |
|
| Download datasheet |
EA-PUL 10500-360 6U
| Manufacturer | EA - Elektro-Automatik |
| Power | 60000.00 W |
| Package | 6U Rack mount |
| No. of outputs | 1 |
EA-PUL 10500-360 6U
| Manufacturer |
|
| Power | 60000.00 W |
| Package | 6U Rack mount |
| No. of outputs | 1 |
| Notes | Water cooling and Integrated function generator options available |
| Input voltage | 380-480Vac ±10% 3-phase |
| Efficiency | 0.97 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Warranty | 2 years |
| Dimensions | 19" x 6U x 668 mm |
| Weight | 76kg (82kg with water cooling) |
| Water-cooled option | Yes |
| Interface options | CAN, CANopen, RS232, Profibus, EtherCAT, Profinet/Modbus/Ethernet (with 1 or 2 ports) |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the consumed DC energy back into the local or public grid with an efficiency up to over 96%. The PUL 10000 series are three phase models, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltages and currents are determined by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 40 A up to 0 - 1000 A in a single device. The DC input operates as a flexible input stage with a constant power characteristic (autoranging) with a wide voltage and current range. To achieve higher power and current all units are equipped with a Master-slave-Bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 3840 W and 64000 A. Such a system works as a single unit and can use different power classes start from 5kW, only the voltage class must remain constant. In this way a user can construct a 150 kW system from two 60 kW and one 30 kW devices from the PUL 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, various optional industrial interfaces, software solutions and many more functions. |
|
| Download datasheet |
EA-PUL 10750-240 6U
| Manufacturer | EA - Elektro-Automatik |
| Power | 60000.00 W |
| Package | 6U Rack mount |
| No. of outputs | 1 |
EA-PUL 10750-240 6U
| Manufacturer |
|
| Power | 60000.00 W |
| Package | 6U Rack mount |
| No. of outputs | 1 |
| Notes | Water cooling and Integrated function generator options available |
| Input voltage | 380-480Vac ±10% 3-phase |
| Efficiency | 0.97 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Warranty | 2 years |
| Dimensions | 19" x 6U x 668 mm |
| Weight | 76kg (82kg with water cooling) |
| Water-cooled option | Yes |
| Interface options | CAN, CANopen, RS232, Profibus, EtherCAT, Profinet/Modbus/Ethernet (with 1 or 2 ports) |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the consumed DC energy back into the local or public grid with an efficiency up to over 96%. The PUL 10000 series are three phase models, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltages and currents are determined by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 40 A up to 0 - 1000 A in a single device. The DC input operates as a flexible input stage with a constant power characteristic (autoranging) with a wide voltage and current range. To achieve higher power and current all units are equipped with a Master-slave-Bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 3840 W and 64000 A. Such a system works as a single unit and can use different power classes start from 5kW, only the voltage class must remain constant. In this way a user can construct a 150 kW system from two 60 kW and one 30 kW devices from the PUL 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, various optional industrial interfaces, software solutions and many more functions. |
|
| Download datasheet |
EA-PUL 10920-250 6U
| Manufacturer | EA - Elektro-Automatik |
| Power | 60000.00 W |
| Package | 6U Rack mount |
| No. of outputs | 1 |
EA-PUL 10920-250 6U
| Manufacturer |
|
| Power | 60000.00 W |
| Package | 6U Rack mount |
| No. of outputs | 1 |
| Notes | Water cooling and Integrated function generator options available |
| Input voltage | 380-480Vac ±10% 3-phase |
| Efficiency | 0.97 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Warranty | 2 years |
| Dimensions | 19" x 6U x 668 mm |
| Weight | 76kg (82kg with water cooling) |
| Water-cooled option | Yes |
| Interface options | CAN, CANopen, RS232, Profibus, EtherCAT, Profinet/Modbus/Ethernet (with 1 or 2 ports) |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the consumed DC energy back into the local or public grid with an efficiency up to over 96%. The PUL 10000 series are three phase models, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltages and currents are determined by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 40 A up to 0 - 1000 A in a single device. The DC input operates as a flexible input stage with a constant power characteristic (autoranging) with a wide voltage and current range. To achieve higher power and current all units are equipped with a Master-slave-Bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 3840 W and 64000 A. Such a system works as a single unit and can use different power classes start from 5kW, only the voltage class must remain constant. In this way a user can construct a 150 kW system from two 60 kW and one 30 kW devices from the PUL 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, various optional industrial interfaces, software solutions and many more functions. |
|
| Download datasheet |
EA-PUL 11000-160 6U
| Manufacturer | EA - Elektro-Automatik |
| Power | 60000.00 W |
| Package | 6U Rack mount |
| No. of outputs | 1 |
EA-PUL 11000-160 6U
| Manufacturer |
|
| Power | 60000.00 W |
| Package | 6U Rack mount |
| No. of outputs | 1 |
| Notes | Water cooling and Integrated function generator options available |
| Input voltage | 380-480Vac ±10% 3-phase |
| Efficiency | 0.96 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Warranty | 2 years |
| Dimensions | 19" x 6U x 668 mm |
| Weight | 76kg (82kg with water cooling) |
| Water-cooled option | Yes |
| Interface options | CAN, CANopen, RS232, Profibus, EtherCAT, Profinet/Modbus/Ethernet (with 1 or 2 ports) |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the consumed DC energy back into the local or public grid with an efficiency up to over 96%. The PUL 10000 series are three phase models, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltages and currents are determined by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 40 A up to 0 - 1000 A in a single device. The DC input operates as a flexible input stage with a constant power characteristic (autoranging) with a wide voltage and current range. To achieve higher power and current all units are equipped with a Master-slave-Bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 3840 W and 64000 A. Such a system works as a single unit and can use different power classes start from 5kW, only the voltage class must remain constant. In this way a user can construct a 150 kW system from two 60 kW and one 30 kW devices from the PUL 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, various optional industrial interfaces, software solutions and many more functions. |
|
| Download datasheet |
EA-PUL 11500-120 6U
| Manufacturer | EA - Elektro-Automatik |
| Power | 60000.00 W |
| Package | 6U Rack mount |
| No. of outputs | 1 |
EA-PUL 11500-120 6U
| Manufacturer |
|
| Power | 60000.00 W |
| Package | 6U Rack mount |
| No. of outputs | 1 |
| Notes | Water cooling and Integrated function generator options available |
| Input voltage | 380-480Vac ±10% 3-phase |
| Efficiency | 0.97 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Warranty | 2 years |
| Dimensions | 19" x 6U x 668 mm |
| Weight | 76kg (82kg with water cooling) |
| Water-cooled option | Yes |
| Interface options | CAN, CANopen, RS232, Profibus, EtherCAT, Profinet/Modbus/Ethernet (with 1 or 2 ports) |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the consumed DC energy back into the local or public grid with an efficiency up to over 96%. The PUL 10000 series are three phase models, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltages and currents are determined by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 40 A up to 0 - 1000 A in a single device. The DC input operates as a flexible input stage with a constant power characteristic (autoranging) with a wide voltage and current range. To achieve higher power and current all units are equipped with a Master-slave-Bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 3840 W and 64000 A. Such a system works as a single unit and can use different power classes start from 5kW, only the voltage class must remain constant. In this way a user can construct a 150 kW system from two 60 kW and one 30 kW devices from the PUL 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, various optional industrial interfaces, software solutions and many more functions. |
|
| Download datasheet |
EA-PUL 12000-80 6U
| Manufacturer | EA - Elektro-Automatik |
| Power | 60000.00 W |
| Package | 6U Rack mount |
| No. of outputs | 1 |
EA-PUL 12000-80 6U
| Manufacturer |
|
| Power | 60000.00 W |
| Package | 6U Rack mount |
| No. of outputs | 1 |
| Notes | Water cooling and Integrated function generator options available |
| Input voltage | 380-480Vac ±10% 3-phase |
| Efficiency | 0.97 |
| Max output current | 0.00 |
| Electronic load input rating power | 0.00 |
| Warranty | 2 years |
| Dimensions | 19" x 6U x 668 mm |
| Weight | 76kg (82kg with water cooling) |
| Water-cooled option | Yes |
| Interface options | CAN, CANopen, RS232, Profibus, EtherCAT, Profinet/Modbus/Ethernet (with 1 or 2 ports) |
Features:
|
|
| Description: The device series from EA Elektro-Automatik ELR 10000 are programmable electronic loads. The device is regenerative and feeds the consumed DC energy back into the local or public grid with an efficiency up to over 96%. The PUL 10000 series are three phase models, which, together with the wide input range, allows use with practically all global mains voltages. The DC voltages and currents are determined by the application and the spectrum ranges from 0 - 80 V to 0 - 2000 V and from 0 - 40 A up to 0 - 1000 A in a single device. The DC input operates as a flexible input stage with a constant power characteristic (autoranging) with a wide voltage and current range. To achieve higher power and current all units are equipped with a Master-slave-Bus. This enables up to 64 parallel connected devices to be combined into one system which can provide a load up to 3840 W and 64000 A. Such a system works as a single unit and can use different power classes start from 5kW, only the voltage class must remain constant. In this way a user can construct a 150 kW system from two 60 kW and one 30 kW devices from the PUL 10000 range. Furthermore, typical laboratory functionality is provided. This includes an extensive function generator, alarm and warning management, various optional industrial interfaces, software solutions and many more functions. |
|
| Download datasheet |
